Capsule Polisher
Capsule polishers of the C&C100C series combine dual functionality for polishing and lifting capsules. The inlet of the polisher can be connected to any model of capsule filler, and the outlet can be connected to a capsule sorter and metal detector. This setup allows for the creation of a production line that ensures polishing, lifting, sorting, and metal detection of capsules. The model is developed using advanced technologies and achievements in robotics.
Why this configuration
Dual functions: polishing and lifting capsules
Compact design frees up additional space for connected equipment
Rotatable inlet and outlet (360°) for convenience and maximum space savings
Sorter automatically rejects capsules with insufficient fill volume, as well as empty, cracked, and split capsules
Quick assembly and disassembly with a reliable design
All parts in contact with the product are made from stainless steel 316L or other materials meeting current pharmaceutical manufacturing standards
Brush can be removed from the main shaft for cleaning
Design eliminates 'dead' zones for effective cleaning, fully GMP compliant
Models with different designs offer various functions, incorporating advanced technologies and achievements in robotics
Talk to a specialist
Get detailed technical specifications, lead times, and export pricing for the capsule polisher.
- Response time
- < 24 hours
- Standard
- GMP
Specifications
| Model | C&C100CS | C&C100CS1 | C&C100C | C&C100CD-L | C&C100CDS-L | C&C100CDS1-L |
| Capsule Size Number | 00# 0# 1# 2# 3# 4# | |||||
| Maximum Productivity | 300,000 pcs/hour | 300,000 pcs/hour | 600,000 pcs/hour | 600,000 pcs/hour | 300,000 pcs/hour | 600,000 pcs/hour |
| Inlet Height | 730 mm | |||||
| Outlet Height | 1260 mm | 890 mm | ||||
| Power Supply | 1 PH 220V/110V 50Hz/60Hz 0.2 kW | |||||
| Compressed Air Consumption | 0.3 m³/min at 0.3 MPa | |||||
| Vacuum Consumption | 3.0 m³/min at -0.1 MPa | |||||
| Dimensions | 740x510x1420 mm | 740x510x1420 mm | 90x510x1420 mm | 490x510x1420 mm | 1220x510x1420 mm | 1220x510x1420 mm |
| Weight | 75 kg | 80 kg | 7 kg | 110 kg | 120 kg | 125 kg |
